Technical Features

Maximum weight of the boat (Kg) 6300

Fluxgate compass yes

Angle of transfer 100 °

Cylinder stroke (mm) 250

Time from stop to stop 4.2

Average consumption (A) 0.5

Teeth number pinion 20

Teeth number wheel 71

Screw Thread : 3 mm

Gear yield : 0.95

Screw yield : 0.85

PRICE 640 €
